Colt M16A1/M16A2 Scope Mounting Bracket



Colt M16A1/M16A2 carrying handle mounting bracket for Tasco armorized 3-9x40 scope

Using the Colt M16A1/M16A2 carrying handle mounting bracket
for the Tasco rubber armorized 3-9x40 scope

top of bracket
Top of bracket

Bracket marked 'M16A1 / M16A2'
Bracket marked 'M16A1 / M16A2'

Bracket marked 'Colt'
Bracket marked 'Colt'

bracket clamps passing through side to side groves
Bracket clamps attach into the sides of the scope and mount,
passing through side to side groves

Full top view of scope

Showing the thumb wheel (left) and terminal bracket (right)
Showing the thumb wheel (left) and terminal bracket (right)

close-up of bracket attached to scope
